Lightware FP-HDMI-TPS-TX97-GB3 HDMI1.4 + Ethernet + RS-232 + bidirectional IR HDBaseT floor box transmitter over CATx cable including PoE. HDCP, 3D and 4K / UHD ( 30Hz RGB 4:4:4, 60Hz YCbCr 4:2:0) compliant. 170m extension distance. Remote powering through MX-TPS2-IB-P/AP/SP boards, MMX6x2-HT series, 25G-8TPS2 boards. Compatible with OBO and Ackermann GB3 frames. - 91540037

List $1,963.50

FP-HDMI-TPS-TX97 series twisted pair HDBaseT™ extenders provide extension of uncompressed 4K/UHD video with embedded audio (up to eight channel PCM or HBR audio) for long distances over a single CATx cable. The unit offers bi-directional RS-232, IR, and Ethernet pass-through on the same CATx cable that carries the video signal. The TPS extenders support full HDCP and EDID compliance and work on all standard AV resolutions up to 4K and 48-bit color depth handling all standard audio formats and also 120 Hz 3D signals. PoE 48V remote powering is available through a single CATx cable, but a local power supply can also be used. All devices can be mounted on a rack shelf or used standalone.

Features

  • Selectable IR output mode for emitter or wired connectivity
  • Bi-directional RS-232 and IR extension (pass-through)
  • Compatible with several standard floor boxed

*All products will be drop shipped from Lightware. For stock availability, please email [email protected]

Shipping
Master product height 0.0
Shipping height (in.) 0.0
Master product width 0.0
Master carton quantity 1.0
Country of origin TW
Master product length 0.0
Quantity unit of measure EA
Shipping width 0.0
Shipping depth 0.0
Shipping weight 0.0
Master product weight 0.0
WP_FP-HDMI-TPS-97_Series_v04.pdf
