Lightware DP-TPS-TX210 DP1.1 + Ethernet + RS-232 + bidirectional IR HDBaseT transmitter with local HDMI output for CATx cable. HDCP, 3D and 4K / UHD (30Hz RGB 4:4:4, 60Hz YCbCr 4:2:0) support. 170m extension distance. Command injection, Autoselect & priority modes, EDID Management. Compatible with 'TPS' series input boards and receivers. - 91540019

List $1,732.50

DP-TPS-TX210 is a compact video, audio and control transmitter over a single CAT cable to up to 170 meter distance for dynamic environments such as small board rooms and classrooms. The extender was designed to handle DP1.1 digital video, embedded audio and control signals.

Features

  • Built-in Event Manager control automation
  • 1920x1080@120Hz/4:4:4 4096x2160@30Hz/4:4:4 or 60Hz/4:2:0 maximum resolutions (300MHz)
  • Ethernet extension (100 Mbps)
  • Command injection on RS-232 and IR ports
  • Bi-directional RS-232 and IR extension pass-through and control
  • Extends DP 1.1 + Audio + Ethernet

*All products will be drop shipped from Lightware. For stock availability, please email [email protected]

Shipping
Master product height 0.0
Shipping height (in.) 0.0
Master product width 0.0
Master carton quantity 1.0
Country of origin TW
Master product length 0.0
Quantity unit of measure EA
Shipping width 0.0
Shipping depth 0.0
Shipping weight 0.0
Master product weight 0.0
DP-TPS-TX210_product_brief-compressed.pdf
