VSN-V3-5-G-RPSU VSN V3 Scalable and ultra-secure video wall controller - Product - Midwich

Mission-critical video wall controllers

Datapath VSN controllers are engineered from the ground up for maximum performance, reliability, and efficiency. They capture, process, and display content on video walls across a range of industries, from small corporate meeting rooms to large critical control rooms and prestige installations.

Installed with Intel processors and memory options, Datapath VSNs can be preconfigured with Datapath Image graphics, Vision capture, and SQX IP decode cards for your specific project requirements. Available with either an 11 or 5 slot backplane.

Power efficiency

The V3 generation introduces the latest technology in power efficiency and system cooling, and chassis enhancements to improve airflow and simplify system maintenance.

The VSN V3 includes support for 12th generation (Alder Lake) Intel Core i9, Core i7 or 10th generation Single Xeon processors, with memory options available of up to 128GB (ECC and non ECC).

Optimized system cooling

The chassis includes hot-swappable fans, enabling uninterrupted 24/7 use and maintenance in the most critical installations. It has been redesigned to further optimize airflow, improve heat management, and reduce noise. This new design, along with a new platinum rated redundant power supply, makes this the most efficient VSN yet.

Reliability

Datapath’s VSN V3 video wall controller has been designed for use in demanding control room environments. Each component has been rigorously tested to ensure high levels of performance and reliability. For added peace of mind, systems can be pre-installed with Wall Monitor software.

Wall Monitor is an application that warns operators if a system begins to function outside of normal parameters. Alarms can be set to indicate changes in voltage and temperature.

Compatibility

The Datapath VSN V3 wall controller is compatible with Windows 10 LTSC 21H2 and Windows 11 LTSC 24H2 operating systems.

TAA Compliant
