The VisionAV-HD is a four lane PCI Express capture card with three video capture inputs - two supporting HD capture and a third supporting SD composite video, these three independent video channels can be captured simultaneously. The VisionAV-HD also adds multiple channels of audio capture, which can be synchronised in software using time stamping with all video capture channels.
This half length full height card features a full mechanical sixteen lane connector with notches which will enable it to fit 4, 8 and 16 lane motherboard connectors.
The VisionAV-HD also adds embedded audio capture from the HDMI signal, which can be sychronised with the respective video channel. This video capture card provides balanced and unbalanced analogue audio capture, through an optional audio module (the Datapath AM2)
This provides a single flexible card solution for areas such as medical, lecture capture, web casting and video conferencing.
TAA Compliant
Four lane PCIe lane bus, Net 1.6 GB/s total capture bandwidth
Triple channel PCI Express capture card
Direct DMA to graphics memory of third party graphics cards
All standard features of the Vision range of capture cards
Driver support included within the Datapath unified Windows driver
Driver support included with the Datapath unified Linux driver
