Lightware VINX-120-HDMI-ENC IP based encoder via a Gigabit Ethernet network. 4K / UHD (30Hz RGB 4:4:4, 60Hz YCbCr 4:2:0) are supported. Advanced EDID Management. USB HID and 2.0 mass storage data support, HDCP2.2 compliant, RS-232 and IR support. - 91810002

List $1,122.00

Extender * Virtual Matrix * Video Wall Processor* KVM Extender

The operation of VINX-120-HDMI-ENC and VINX-110-HDMI-DEC can be expanded from a simple point-to-point application to unlimited endpoints for the ultimate in virtual matrix switching, digital signage and signal extension. The extenders include our Advanced EDID Management system and decoders are capable of scaling the video signal up to the maximum supported resolution of 4K UHD @ 30 Hz. RS-232 and IR control channels are supported. The built-in USB ports support KVM function and can also handle USB 2.0 mass storage. The units are HDCP compliant.

Silent Operation

The efficient design of all VINX models allows passive, fanless cooling. VINX have noiseless operation, fitting even the most silent application environments.

Features

  • USB 1.1K+M (HID) extension
  • USB 2.0 MSC (Mass Storage Class) extension
  • Built-in website for device configurations

*All products will be drop shipped from Lightware. For stock availability, please email [email protected]

Shipping
Master product height 0.0
Shipping height (in.) 1.0
Master product width 0.0
Master carton quantity 1.0
Country of origin TW
Master product length 0.0
Quantity unit of measure EA
Shipping width 4.0
Shipping depth 4.52
Shipping weight 0.81
Master product weight 0.0
VINX-120-HDMI-ENC_Product_Brief.pdf
