Taurus UCX 2x1 switcher with TPN, USB-C, HDMI 2.0 and USB 2.0 ports. Full 4K HDMI 2.0 TPN transmitter (4K UHD @ 60Hz RGB 4:4:4, up to 18 Gbps). USB-C connectivity for video, audio, USB 2.0 signals and charging via USB-C up to 100W. 10 GbE Port for SDVoE network connection with 4K video and USB 2.0 transmission. Advanced room automation/control features.

Universal transmitter switcher is part of the AV over IP ecosystem with SDVoE technology that provides the same functionality as the UCX product range from a single source to multiple destinations through 10G Ethernet networks.

• UCX-TPN combines Full-Featured USB-C and SDVoE
• HDMI2.0 4K@60 4:4:4 matrix switching over 10G network
• Independent, full bandwidth USB 2.0 matrix switching layer, supporting multiple USB camera sources
• Taurus UCX, DCX and HDMI-TPN devices can be combined in a media-over-IP matrix switching system

Features

• USB-C charging up to 100W
• Multiple USB 2.0 connectivity for any type of USB device (Camera, speakerphone, touch monitor, USB-HID devices etc.)
• Room device control via Ethernet (TCP/IP), Serial, OCS or local GPIOs
• Independent USB Host switching layer for multiple USB hosts, for devices connected to TPN receivers and for 4 devices at TX side
• Video, Audio, Data and Charging Power over a single USB-C connection
• Allows for the transmission of USB-C, HDMI 2.0, embedded audio, Ethernet, RS-232 to multiple TPN receiver devices through a 10G Ethernet switch
• Integrated SDVoE Control Server
