Turtle AV CHAZY 4K USB-C TX - Product - Midwich

The Chazy 4K USB-C Tx is a Dante AV-A and JPEG 2000 encoder, allowing seamless transmission of 2160 60Hz 4:4:4 HDR video from laptops or tablets via USB-C, and from video sources via the HDMI 2.0b input. The Dante AV-A license is included and ready to go, which also has 2x2 Dante audio license. Chazy 4K USB-C Tx is PoE powered and supports a wide range of audio formats including 7.1 Dolby Atomos, and features advanced capabilities like KVM, video wall configurations up to 9x9, hardware scaling, EDID management, HDCP 2.2, and true multicast support. TAA compliant, Chazy 4K USB-C Tx also comes with a 5-year warranty.

Key Features:

• Dante AV-A™ & JPEG 2000
• Dante AV-A™ licence included with 2x2 Dante audio
• 2160 60Hz 4:4:4 HDR
• USB-C video input
• PoE and 12V DC
• HDCP 2.2 & EDID Management
• 7.1ch Dolby Atomos Audio
• KVM and Video Wall up to 9x9
• Dual network ports
• TAA Compliant
• 5 Year Warranty

Dante AV-A & JPEG 2000

Bridging the best of both worlds, Dante AV-A works seamlessly with Dante Controller for full routing ability, whilst JPEG 2000 is a visually lossless, super low latency video codec.

Dante AV-A included

Chazy 4K USB-C Tx comes with the Dante AV-A licence included so there are no hidden costs and nothing left to do other than plug them in, and open up Dante Controller to start your routing.

Dante Audio Included

With the included Dante AV-A licence, the Chazy 4K USB-C Tx also includes 2x2 Dante Audio. Extract audio from an HDMI source and send it to external speakers via Dante’s 2x2 audio channels.

Dante AV-A in hardware

The optional Chazy Control box takes Dante Controller a step further by building it into hardware. The benefits of this include:

• No need to run any software
• You can now control your entire Dante network from any device with a web browser including iPad, Tablet, Smartphone.
• Control from Q-SYS, Crestron, and more using the free API.

Advanced EDID Management

The Chazy 4K USB-C Tx simplifies connections with advanced EDID management, featuring automatic detection and the ability to load custom EDID tables directly through the WebGUI.

Hardware scaler built in

The integrated hardware enables precise resolution matching and color space conversion between sources and displays eliminating issues with unsupported formats, scaling artifacts, or mismatched color profiles.

Audio. Audio. Audio.

• 7.1-channel Dolby Atmos.
• Dolby TrueHD.
• Dolby Digital Plus.
• DTS-HD Master Audio.
• ARC & eARC.
• SPDIF connectivity.
• Analog audio return via Phoenix Connectors.

And yes, Dante 2x2 Audio licence included so you can route any of the above to 2-channel Dante and vice versa.
