The Server Core X50r is the most powerful AV&C processor on the market, combining the Q-SYS Full Stack AV Platform with industry-proven server hardware to deliver an abundance of DSP processing power and network audio capacity to serve the most demanding and complex large-scale AV deployments, from themed entertainment and resorts to large venues and more.

Features & Benefits

• 4096 x 4096 networked audio channels (with 10 Gbps network connection only—512 x 512 channels @ 1 Gbps)
• 1024 x 1024 network I/O streams @ 10 Gbps (256 x 256 @ 1 Gbps)
• 256x AEC channels @ 200 ms
• Includes 8 x 8 Software-based Dante channels (licensable up to 512 x 512)
• Dual redundant, hot-swappable power supplies
• 4x 10Gbps capable SFP+ ports (pre-installed 2x 10Gbps fiber / 2x 1Gbps copper RJ45; field-replaceable)
• 256 x 256 Media/WAN channel capacity
• 16 multitrack playback channels (up to 256 with optional stackable feature license)
• 4 multitrack record channels
• Onboard 960 GB media drive
• 2RU form factor

Q-SYS X-Class Server Core for AV&C processing built on Dell PowerEdge Server Technology offering up to 4096x4096 networked audio channels when connected to a 10Gbps network, with 8x8 Software-based Dante license included, dual SFP+ Ethernet ports for network redundancy (populated with 10Gbps fiber optic transceivers), plus two auxiliary SFP+ Ethernet ports (populated with 1Gbps copper RJ45 transceivers), 256 next-generation AEC processors, dual redundant hot-swappable power supplies.
