NovaStar MX30 All-in-One LED Display Controller - MX30

List $2,868.00
MAP $2,868.00

NovaStar MX30, part of the COEX series, is an all-in-one LED display controller that integrates video processing and video control into one box and offers rich video input connectors (HDMI 2.0, HDMI 1.4, DP 1.1 and 3G-SDI), 10x Ethernet output ports and 2x 10G optical ports. It can also work with NovaStar’s VMP software (Vision Management Platform) to provide a better operation and control experience.



 MX30
 Loading Capacity

 6.5 Million
 Modular Design  x
 Input Card Qty  N/A
 Output Card Qty  N/A
 Chassis Height  2U
INPUTS
 Input Interface

 1×HDMI 2.0
 (IN+LOOP)

 1×HDMI 1.4
 (IN+LOOP)

 1×DP 1.1

 2×3G-SDI
 (IN+LOOP)
 Input Bit Depth  8bit
 10bit
 Max. Input Width  8,192
 Max. Input Height  7,680
OUTPUTS
 Output Interface

 10×1G Neutrik

 2×10G OPT
 Layers  3
 Max. Output Width  16,384
 Max. Output Height  16,384
GENLOCK
Shipping
Master product height 0.0
Shipping height (in.) 0.0
Master product width 0.0
Master carton quantity 1.0
Country of origin CN
Master product length 0.0
Quantity unit of measure EA
Shipping width 0.0
Shipping depth 0.0
Shipping weight 0.0
Master product weight 0.0
