MX2-32x32-HDMI20-A-R HDMI 2.0 Compatible 32x32 Standalone Matrix Router - Product - Midwich

MX2-32x32-HDMI20-A-R is a member of the MX2 standalone matrix switcher series supporting uncompromised 4K UHD resolution at 60Hz with RGB 4:4:4 colorspace and with down-conversion capabilities to 4:2:0. These routers are fully HDMI 2.0 compatible. The switchers have outstanding port density making them particularly suitable for fix-install applications and for future-proof operation centers alike: for installations where a huge number of HDMI 2.0 compliant input and output ports are required.

Features

• HDCP 2.3 and HDCP 1.4 compliant with cross conversion capabilities
• Supports HDMI 4K signal formats 4K UHD @60Hz RGB 4:4:4, up to 18 Gbps
• HDMI 2.0, HDMI 1.4 and DVI 1.0 compliant
• HDR and Low Latency Dolby Vision support
• High bitrate Audio Support including Dolby Atmos, TrueHD, DTS-HD
• Uncompressed video up to 18 Gbps datarate (600 MHz pixel clock)
• No signal latency, zero frame delay
• Supports HDMI 5K signal formats 5120x2160 HDMI 2.0: 30Hz 4:4:4 or 60Hz 4:2:0

*All products will be drop shipped from Lightware. For stock availability, please email [email protected]
