KIT-401 4K Auto-Switcher / Scaler Kit over Long Reach HDBaseT - Product - Midwich

4K Auto-Switcher / Scaler Kit over Long Reach HDBaseT

• Includes wall–plate transmitter & compact receiver
• Resolution support up to 4K@60Hz (Receiver — 4:4:4; Transmitter — 4:2:0)
• PoC Powered
• Up to 40m (130ft) at 4K@60Hz (4:2:0)
• Up to 70m (230ft): at full HD (1080P@60Hz)
• Simple and Powerful Maestro Room Automation
• Built–in relay and contact closure connections
• HDCP 2.2 & 1.4 compliant

KIT−401 is a high−performance auto−switcher/scaler kit for 4K HDMI™ and VGA over long−reach HDBaseT. The kit includes the KIT−401T wall−plate transmitter/switcher and the KIT−400R receiver/scaler. The KIT−401T transmitter converts the user−selected input signal into the transmitted HDBaseT signal. The KIT−400R receiver receives the HDBaseT signal, converts it to HDMI and up− or down−scales the picture to match the resolution of the HDMI monitor. KIT−401 extends video signals to up to 40m (130ft) over CAT copper cables at up to 4K@60Hz (4:2:0) 24bpp video resolution and provides even further reach for lower HD video resolutions.
