The HDMI-TPX-TX209DU2K and HDMI-TPX-RX109DU2K transmitter and receiver devices with Dante audio are based on SDVoE technology and allow users to extend HDMI 2.0 compliant video, audio and control signals from a single source to a single destination when they are directly connected. Moreover, these USB2.0 capable extenders also allow transparent and composite USB2.0 transmission in the opposite direction.

Features

• USB2.0 transmission with support for USB2.0 devices e.g. cameras, microphones, touch screens, pen drives, keyboard and mouse
• Can send or receive remote power through CATx cable (PoE PSE, PoE PD)
• Allows for the transmission of HDMI 2.0, embedded audio, Ethernet, RS-232 and USB2.0 between an extender pair directly connected together
• Supports HDMI 4K signal formats (4K UHD @60Hz RGB 4:4:4, up to 18 Gbps)
• HDR and Low Latency Dolby Vision support
• 2 channels of LPCM audio embedded in the HDMI stream can be de-embedded to Dante/AES67 streams

*All products will be drop shipped from Lightware. For stock availability, please email [email protected]
