Fiber Optical Extender for HDMI 2.0 Signals

The HDMI-OPTX-TX200AU2K and HDMI-OPTX-RX100AU2K transmitter and receiver devices are fiber extenders based on SDVoE technology and allow users to extend HDMI 2.0 compliant video, audio and control signals from a single source to a single destination through a fiber optical link. Moreover, these USB2.0 capable extenders also allow transparent and composite USB2.0 transmission in the opposite direction.

Features

• Transmission distance of up to 10km when SM SFP+ module is used
• Allows for the transmission of HDMI 2.0 embedded audio, Ethernet, RS-232 and USB2.0 between an extender pair through single mode or multimode fiber
• SFP+ cage for single mode or multimode SFP+ modules
• Transparent USB transmission mode for various USB2.0 devices including cameras, microphones, and touch screens and composite USB transmission mode for USB-HID devices
• Supports HDMI 4K signal formats 4K UHD @60Hz RGB 4:4:4, up to 18 Gbps
• HDR and Low Latency Dolby Vision support

*All products will be drop shipped from Lightware. For stock availability, please email [email protected]
