Lightware HDMI-3D-OPT-TX210RAK HDMI1.4 fiber optical transmitter with USB KVM, SC fiber connector, local HDMI output and analog balanced audio input. 4K / UHD (30Hz RGB 4:4:4, 60Hz YCbCr 4:2:0), 3D and HDCP support. Bidirectional RS-232 extension, Pixel Accurate Reclocking, 2500m extension using OM3e fiber. - 91510030

List $3,217.50

Long-Distance HDMI Signal Extension

HDMI-3D-OPT-TX210RAK extends HDMI 1.4 signals over one multimode fiber and transmit video signal with embedded audio to a distance of up to 2500 meters.

High-Quality Video and Audio Handling

The extender was designed to handle HDMI 1.4 digital video signal and analog stereo audio from local inputs or HDMI embedded audio up to eight channel PCM or HBR audio. Analog audio is converted into digital format. The device has a local HDMI video output for monitoring. The video and the embedded audio of the local output is the same as the one transmitted via the OPT link. The HDMI-3D-OPT-TX210A handles HDCP encryption.

Features

  • 1920x1080@120Hz/4:4:4 4096x2160@30Hz/4:4:4 or 60Hz/4:2:0 maximum resolutions (300MHz)
  • Bi-directional RS-232 extension (pass-through and control)
  • Extends HDMI 1.4, USB KVM and RS-232 signals over one multimode fiber cable
  • Single Fiber Technology
  • USB KVM (HID) extension
  • Audio embedding from 3.5mm jack or 5-pole balanced Phoenix connector
  • Local monitor output on transmitter

*All products will be drop shipped from Lightware. For stock availability, please email [email protected]

Shipping
Master product height 0.0
Shipping height (in.) 0.0
Master product width 0.0
Master carton quantity 1.0
Country of origin TW
Master product length 0.0
Quantity unit of measure EA
Shipping width 0.0
Shipping depth 0.0
Shipping weight 0.0
Master product weight 0.0
HDMI-3D-OPT-TX210A_HDMI-3D-OPT-TX210AS_HDMI-3D-OPT-TX210RAK.pdf
