Lightware's revolutionary GEMINI GVN 1Gb AV-over-IP extender family, where scalability, flexibility, and rapid deployment take center stage. Designed to meet the demands of modern audiovisual environments, the GEMINI GVN is a virtual matrix system that seamlessly switches audio, video, and USB transmission with unparalleled ease.

At the heart of the GEMINI GVN system is the Matrix Management Unit (MMU) device, providing full functionality from a centralized control point, eliminating the need for individual endpoint configurations. With seamless switching capabilities, users can effortlessly manage their audiovisual setup for optimal performance.

Equipped with Lightware's Advanced EDID Management system, the GEMINI GVN ensures that the decoders are capable of scaling HDMI 2.0 video signals up to a maximum resolution of 4K UHD @ 60 Hz either on CAT (up to 100 meters) or on fiber optics (up to 10 kms) with HDR, HDR+, and Dolby Vision support.

Supporting RS-232 control channel, the GEMINI GVN offers enhanced control options for a seamless user experience. The built-in USB ports support KVM functionality and can handle USB 2.0 touch screen, webcam, mass storage, further enhancing connectivity and versatility.

Compliant with HDCP standards, the GEMINI GVN guarantees secure content transmission. With support for the DHCP network management protocol, configuration and management become effortless, simplifying system integration.

Features

• SFP cage for single mode or multimode SFP modules (the optical module is not part of the product)
• Transmission distance of up to 80km (when SM SFP module is used)
• Transmission distance of up to 550m (when MM SFP module is used)
• Supports PoE PD (IEEE 802.3af)
• HDMI 2.0 input up to 4K@60Hz 4:4:4 resolution
• HDCP 2.2 support
• Visually Lossless Video Codec (proprietary codec based on JPEG2000)
• Zero frame latency (~3 ms end-to-end latency at 4K60 transmission)
• Local HDMI 2.0 output up to 4K@60Hz 4:4:4 resolution
• All audio formats supported by the HDMI 2.0 standard are supported up to 7.1-channels, LPCM, compressed audio and High-Bitrate audio (e.g. DTS-X, Dolby Digital, Dolby Atmos)
• Analog audio support (LPCM stereo) with selectable direction (input or output)
• Offers a RS-232 port
• Support the distance up to 100m (328ft) between the transmitter endpoint and Network Switch (Cat5e)
• Supports full USB2.0 over IP
• 2×2 channels of Dante/AES67 audio
• Supports USB K+M (keyboard and mouse) over IP
