4−channel 4K@60Hz (4:2:0), long reach, HDBaseT output card - DT-OUT4-F32/STANDALONE

List $1,198.00
MAP $958.40

DT−OUT4−F32 is a four−channel 4K@60Hz (4:2:0), long reach, HDBaseT output card for the VS−3232 Series Modular Multi−Format Digital Matrix Switchers. DT−OUT4−F32 outputs four long reach HDBaseT signals with bidirectional RS−232 and IR from the chassis to the line.

  •  Max. Data Rate — 10.2 Gbps (3.4 Gbps per graphic channel).
  •  System Range — 40m (130ft) — 4K60 4:2:0 or 4K30 4:4:4; 70m (230ft) — 1080p 12bit (deep color). Note: When using Kramer HDBaseT cables.
  •  HDTV Compatible.
  •  HDCP Compliant.
  •  3D Pass–Through.
  •  Bidirectional RS–232 and IR per Port.
  •  Kramer Equalization and re–Klocking Technology.

Shipping
EAN code 7291063080006
Shipping height (in.) 2.13
Master carton quantity 1.0
Shipping width 9.0
Shipping depth 10.5
Shipping weight 0.95
Master product height 0.0
Master product width 0.0
Master product length 0.0
Quantity unit of measure EA
UPC code 7291063080006
Master product weight 0.0
DT-OUT4-F32.pdf
