Universal transmitter switcher is part of the AV over IP ecosystem with SDVoE technology that provides the same functionality as the DCX product range providing seamless integration of diverse multimedia signals over distances of up to 100 meters, while working in a point-to-point arrangement through 10G Ethernet networks.

• DCX-TPX combines USB-C and SDVoE technologies
• HDMI 2.0 4K@60 4:4:4 matrix switching over 10G network
• 5K (5120×2160) via HDMI 2.0 at 30Hz 4:4:4 or 60Hz 4:2:0
• Taurus UCX, DCX and HDMI-TPX devices can be combined

Supporting 5K

Taurus devices deliver flawless switching for 5K 21:9 ultrawide displays, unlocking a new level of visual performance for modern meeting and control environments. Designed to enhance layouts like Microsoft Teams Front Row and other collaboration platforms, Taurus provides expanded screen real estate for design, data visualization, and multi-window workflows. With uncompressed HDMI 2.0 video and ultra-low latency, it’s the ideal choice for simulation, engineering, broadcast, and executive boardroom applications.

Features

• Video, Audio and Charging Power over a single USB-C connection
• Allows for the transmission of USB-C, HDMI 2.0, embedded audio, Ethernet, RS-232 to TPX receiver devices
• USB-C charging up to 100W
• Integrated SDVoE Control Server
• Remote system logging
• Supports HDMI 5K signal formats 5120x2160 HDMI 2.0: 30Hz 4:4:4 or 60Hz 4:2:0

*All products will be drop shipped from Lightware. For stock availability, please email [email protected]
