BT7518/B Flat Screen Wall Mount - Product - Midwich

Designed to mount small flat screens, this wall mount features both swivel and tilt functions. With the distance to wall at 93mm it allows easy positioning and a full 3600 rotation of the screen. Cover plates are included to hide fixings helping make this a neat and tidy mounting solution. BT7518 is also collar compatible for alternative mounting solutions, ideal for commercial applications as well as home installations.

Features

• Fits screens with VESA® mounting patterns: 75 x 75mm and 100 x 100mm
• Easy tilt , swivel and screen rotation adjustment
• Mounts screen only 93mm from the wall
• Features ‘OWLS’ On Wall Levelling System
• Security locking screws and Allen key provided for secure installation
• Simple ‘hook-on’ installation with all mounting hardware included
• Compatible with B-Tech accessory collars

Specifications

• Recommended screen size: up to 28" (71cm)
• Max load: 20kg (40lbs)
• VESA® compatibility: 75 x75 & 100 x 100
• Extension: 93mm (3.6")
• Tilt: +17/-10˚
• Swivel wall mounted: 50˚
• Swivel pole mounted: 180˚
• Screen rotation: 360˚
• Color: Black
