Q-SYS 4.5" Two-way ceiling speakers, 70/100V transformer with 16Ohm bypass, zero bezel design, 150 conical DMT coverage, includes C-ring and rails for blind mount installation. Priced individually, must be purchased in pairs. White Only. - AD-C4T-LPZB-WH

List $265.00
MAP $265.00

The Q-SYS AcousticDesign™ AD-C4T-LPZB is a 4.5” two-way, low profile, zero bezel ceiling loudspeaker ideally suited for a wide variety of foreground and background sound reinforcement applications which utilize 70/100V or 16Ω bypass configurations.

Features:

  • Consistent tonal characteristics across the entire AcousticDesign™ family in both surface or ceiling applications
  • Sleek zero bezel design for modern architectural needs
  • Directivity Matched Transition® (DMT) waveguide ensures smooth, uniform frequency response over the coverage area
  • Snap-fit magnetic grille
  • 3x double stepped, long travel dog-ear blind mount system
  • Advanced Intrinsic Correction™ voicings available via Q-SYS™
  • Low-saturation and low-loss 70/100V transformers with 16Ω bypass
  • Blemish-free removable logo
  • Removable conduit cover plate, also available as accessory for pre-install wiring
  • UL1480 and UL2043 certified
  • Available in signal white (RAL 9003), with black grille accessory sold separately

Certifications and Compliances
Certified for Microsoft Teams
Shipping
Harmonize code 8518.22.0000
UPC code 684284089274
Master product height 0.0
Shipping height (in.) 7.2
Master product width 0.0
Master carton quantity 1.0
Country of origin CN
Master product length 0.0
Quantity unit of measure EA
Shipping width 27.5
Shipping depth 15.5
Shipping weight 22.5
Master product weight 0.0
q_spk_ad_c4t_lpzb_specsheet.pdf
